Pilbara

The Trakmaster tradition of designing and building the toughest of Off-Road caravans since 1995 is continued with the Pilbara, like the country from which it is named, it's also as tough as iron.

With increased ground clearance and steeply raked rear end and the fully insulated CFP Impact Resistant Wall Structure the Pilbara will appeal to the remote area traveller. Offering a broad size range the Pilbara will satisfy even the most adventurous.

Size Range (Pop-Top)

Length 3.8 metres (12'6″) to 5.0 metres (16'6″) Internal body length
Width 2.0 metres (6'8″) to 2.3 metres (7'6″) External

Size Range (Full Height)

Length 4.6 metres (15′) to 6.1 metres (20′) Internal Body Length
Width 2.1 metres (7 feet) to 2.3 metres (7'6″) External

Design Features

Increased Ground Clearance (Trakmaster “NEWGEN” chassis design)
150mm x 50mm “One Piece” Chassis Rails
Increased Departure Angle (Trakmaster “EXTREME” X-Country rear cutaway)
Integrated Spare wheel Mount (fitted on ratchet system under rear of van)
Fully Insulated Impact Resistant CFP Wall Structure
30% Increase In Wall Insulation Properties
SUGARGLIDER Independent Trailing Arm Coil Spring Suspension System
Long Travel 150mm (6″) Diameter Coils (standard) Tailored to the Individual Van
40mm Large Bore Trakrider Shock Absorbers
