Professional AI Series 4.0MP Motorised Bullet - VIP Vision

Featuring intelligent perimeter protection, the VSIPP-4BIRMG-I identifies people & vehicles during motion detection to filter out false alarms, providing reliable real-time alerts and analytics. Achieving high quality video evidence with colour in low light & true WDR, the series excels at outdoors motion detection applications. Camera features: • Stream up to 4.0MP (2688 x 1520) at 20fps • 2.7 ~ 13.5mm motorised lens with 104 ~ 27° viewing angles • H.265 encoding for efficient storage & streaming • Up to 60m infrared range; true day/night (auto ICR) • MicroSD slot for recording at the edge up to 256GB • AI powered perimeter protection video analytics • Set up AI powered tripwire & intrusion rules, receive alerts and search footage by people or vehicles • Back/highlight compensation & true WDR (120dB) • 3D digital noise reduction & auto white balance • IP67 weather rated housing for outdoor use   Specifications Camera Image Sensor 1/3’’ 4.0MP Progressive Scan CMOS Effective Pixels 2688 (H) x 1520 (V) RAM / ROM 128MB / 128MB Min Illumination 0.008 Lux/F1.5 (Color) S/N Ratio > 50dB Infrared System 4 x Infrared LED, 60m range, Auto/manual on/off control Lens Lens / Iris 2.7 ~ 13.5mm F1.5 Motorised Varifocal Lens with Fixed Iris Field of View Horizontal: 104°~27°, Vertical: 55°~15° (5x Optical Zoom) Focus Auto Focus / 0.8m Min. Focus Distance DORI Detect (25px/m) 64m (wide) / 220m (tele) Observe (63px/m) 26m (wide) / 88m (tele) Recognise (125px/m) 13m (wide) / 44m (tele) Identify (250px/m) 6m (wide) / 22m (tele) Video Resolution 4.0MP (2688 x 1520) to CIF (352 x 288) Frame Rate (Main) 4.0MP (1 ~ 20fps) / 3.0MP (1 ~ 25fps) Frame Rate (Sub) D1 (1 ~ 25fps) Frame Rate (Third) N/A Video Compression H.265 / H.264 / H.264B / MJPEG Bit Rate H.265: 12 ~ 6144Kbps / H.264: 32 ~ 6144Kbps Bit Rate Control Constant bit rate (CBR) / Variable bit rate (VBR) Day/Night Auto (ICR) / Color / B&W Lighting Compensation BLC / HLC / WDR (120dB) White Balance Auto / Natural / Street Lamp / Outdoor / Manual / Regional Custom Gain Control Auto / Manual Noise Reduction 3D DNR Picture Control Mirror / Flip (0°, 90°, 180°, 270°) IVS Intelligent Functions Motion Detection (4 zones), Region of Interest (4 zones), Privacy Masking (4 zones), Smart Infrared Perimeter Protection Tripwire, Intrusion (recognition of human or vehicle) Face Detection With a smart NVR intelligent search. Search tripwire/ intrusion events by people or vehicle. Face Attributes RJ-45 (10/100Base-T) People Counting N/A Heat Map N/A Event Trigger N/A Intelligent Search With a smart NVR intelligent search. Search tripwire/ intrusion events by people or vehicle. Network Ethernet RJ-45 (10/100Base-T) Protocol IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour Streaming Method Unicast / Multicast Max. User Access 20 Users Interface Video Interface N/A Audio Interface 1 input (RCA Port) / 1 output (RAC Port) / Audio Compression - G.711a; G.711Mu; G726; AAC Alarm Interface 1 channel in: 5mA 5VDC/ 1 channel out: 300mA 12VDC RS485 N/A Edge Storage MicroSD Card (up to 256GB) / NAS Interoperability ONVIF / P2P / CGI / Milestone / Genetec Environmental Power Supply 12VDC / PoE (802.3af) Power Consumption
