SBC5936 24V 12A DC-DC BATTERY CHARGER WITH DUAL INPUTS DC & SOLAR INPUTS AUTO SELECT 12V 24V

24V 12A DC-DC Battery charger with dual input (SOLAR MPPT & DC) & auto select 12V/24V input The SBC-5936 is designed to address the issues of the wide swing of output voltages from the smart alternator, start & stop, braking regenerative EURO 5/6 vehicles in fully charging the house battery. It is suitable for use with all old alternator systems and distant house batteries. There are 3 alternator charging modes available, Factory Preset Mode, Ignition Feed Mode, and Vibration Sensor Mode. The built-in vibration sensor makes it possible to use the charger by just connecting to the starter battery terminal without touching the car’s electrical/ electronic wiring thus avoiding any possible excuse of revoking the car’s warranty. The digital control and auto-select design of SBC-5936 make it automatically adapt to a 12V or 24V input alternator/ battery system. This is an automatic dual-input solar & alternator-battery charger for charging 12V house battery banks of lead acid, AGM type II, and Lithium Fe Po4 batteries. The built-in Solar charge controller is of Maximum Power Point Tracking (MPPT) technology which maximizes the PV power from your 12V solar panels to your house battery. In the 12V alternator/ battery system, the house battery is charged by both Solar and alternator/ battery simultaneously to maximize the free solar energy. **In the 24V alternator/ battery system the house battery is charged by Solar only when the car’s alternator/ battery stops charging operation. This is a select (battery type) and forget charger designed for fast and accurate recharge of your deep cycle house battery. The smart multi-stage charging enables the charger to be connected permanently to your battery banks without the worry of overcharging or drying out the electrolyte. Lead Acid Based Battery A 3 Stage Bulk, Absorption & Float charging profile with maximum constant charging current at the Bulk Stage a Constant Voltage with decreasing charging at the Absorption Stage, and a reduced voltage Float Charge for maintenance when the battery is full. LiFePO4 (LFP) Battery A 2 Stage charging is especially for the LiFePO4 battery and the charging current stops at the end of the Absorption Stage. FEATURES Dual Input from a car battery with alternator and Solar panel; Auto select for 12V or 24V car system; Design all alternators, conventional and smart alternators; 3 DC Charge Modes to select: Vibration Sensor Mode Ignition Feed Mode with Automatic or Manual Control setting. Factory Preset Mode ( charging function always on ) Suitable for Lead Acid, AGM, and LiFePO4 battery; Protections: Self Recoverable Input Under Voltage Protection; Self Recoverable Output Over Voltage Protection; Self Recoverable Over Temperature Protection; Self Recoverable Over Load Protection (C.C.) with constant current at decreased output voltage; Self Recoverable Input Reverse Polarity Protection; Output Reverse Polarity Protection by Thermal Fuse; Auto select for 12V or 24V car system. WHAT IS IN THE BOX? SBC5936 charger x 1pc Remote LED Indicator Module (with 2M cable) x1pc Heavy duty electrical eye connectors x 4pcs Plastic wire guide x 1pc Double-side sticker tape for the Remote Indicator Module x 1pc Wire for Pin Connections x 2pcs Spare 8 Pin Connection sticker label x 1pc SPECIFICATIONS Input Voltage 9-32VDC PV input Yes (Max OCV 30V) Output Voltage Max 30V Max charging current 12A Recommend Max battery size 100AH Efficiency 89% (Optimal) Support battery types LEAD, AGM, LiFePO4 User define battery type Not Apply Power supply mode No Number of output 1 Number of charging stage 3 stage for LEAD and AGM, 2 stage for LiFePO4 Equalization No Soft-start Yes standby mode Not Apply Display LED indicators Minimum Battery Voltage 10V Protection Input & Output reverse polarity protection, Input Under Voltage protection, Output Over Voltage protection, Over Load, Charger Over Temperature. Cooling Method Thermostatically speed control Fan Remote Battery temp. sensor Bundle Accessories Double side sticker tape, 4 heavy duty electrical eye connectors, One plastic wire guide, Two thin wires for Pin Connections, One spare 8 pin Connection sticker label, Battery Temperature Sensor Operation Temperature -10°C to 50°C (Can give full output at 40°C) Dimensions 200x130x55 mm Weight 1kg   SBC5936 Manual PDF file Barcode Number: 9328202035103
