Razor Multi 220 Bundle Unimig PK11092

RAZOR MULTI 220 BUNDLE UNIMIG PK11092

BOX INCLUDES:

RAZOR MULTI 220 (U11008K)
Trade Series Welding Helmet - Dragon (U21027)
BINZEL 24 Style Consumable Starter Kit (UMSK24)
15A 2.5mm Heavy Duty Extension Lead 10m (U51006)
0.9mm HYPERMIG ER70S-6 Mild Steel Wire 5kg (MS.9B)
ROGUE Heavy Duty Welding Gloves (UMWG8)

FEATURES:

Smart-Set MIG: Getting set up for a weld has never been faster with our preset synergic programs. Simply select your wire, type, wire size, gas type and material thickness, and the machine does the rest. It'll pick the optimal settings for your weld.
Multi-process: Get the job done quickly and efficiently with our versatile three-in-one welding machine. With the ability to perform MIG, TIG, and MMA welding all in one unit, it's also capable of running both gas-shielded and gasless MIG wire, so you can tackle a wide variety of welding projects with ease. Whether you're working with mild steel, stainless steel, aluminium, or flux-cored wire, our machine has got you covered, saving you valuable time and effort without sacrificing quality.
HD Backlit Control Panel: The high definition backlit screen presents your welding parameters in a clean, easy to follow layout. Clear numbers, simple icons and a structured interface make adjusting your settings fast, intuitive and effortless.
Accessories: Ready for any kind of welding you've got planned, connect a complete range of MIG, TIG or MMA accessories to your welder.
Spool Gun: Make welding aluminium even easier. No need to change your existing setup. The spool gun lets you quickly switch over and get any job done with no downtime.
TIG Torch: The Trigger Controlled DC Lift Arc ignition allows the arc to be started easily in DC TIG by simply touching the tungsten to the workpiece and lifting it up to start the arc. This stops the tungsten tip from sticking to the workpiece and breaking the tip from the tungsten electrode.
Foot Pedal: Enjoy greater control and precision with our optional foot control accessory. This handy feature allows you to easily adjust your TIG amperage on the fly, without interrupting your torch movement.
Digital Control MIG Torch: Make live adjustments from the torch using simple digital buttons for amperage or voltage changes. The machine screen updates instantly, giving you accurate feedback while you weld. A clean, tactile control layout lets you adjust settings with ease.
Geared Wire Drive: For a consistent and smooth wire-feeding experience. The geared wire drive unit gives more power pushing to the wire, improving the wire feeding, especially in longer torches.
Advanced IGBT Inverter Technology: Our IGBT inverter platform delivers higher efficiency, stronger arc stability and more consistent power delivery. It runs cooler, responds faster to changes in arc demand and provides the reliability needed for modern welding applications.
Smart Fan Technology: The fan runs only when needed, reducing noise, cutting power use and limiting the dust drawn into the machine. This keeps internal components cleaner and helps extend the overall life of the unit.
Active Airflow System: The active air passage channels airflow through the machine while keeping dust away from critical electrical components. This improves cooling efficiency, protects the internals and helps extend the life of your welder.
IP23S Protection Rating: Rated IP23S for reliable performance in demanding welding environments. Built to handle tougher conditions and maintain dependable operation where durability matters.
Advance MMA Features: Advanced MMA features are designed for improving weld quality and ease of use.
Arc Force: The Arc Force feature helps to keep the arc stabilised throughout the weld, by increasing or decreasing the peak current to compensate for your arc length, preventing the arc from cutting out or the electrode from sticking.
Hot Start: The adjustable hot start is designed to help with striking an arc. The hot start temporarily boosts the output current at the start, making striking an arc, even with difficult electrodes, much easier. You get smoother arc starts, improving the quality of your weld.
Anti-Stick: The Anti-Stick feature, which is always on, prevents your electrode from sticking to your workpiece. When the machine detects sticking, the current will drop significantly, so the electrode can be removed.
Generator Compatible: Take it anywhere. Connect the machine to a generator and use it wherever, whenever you need it. We recommend 12kVA for this machine.
Lightweight & Portable: Weighing just 15kg, the RAZOR MULTI 220 comes in a small carry case, ready to go anywhere you need it.

SPECIFICATIONS:

MACHINE SPECIFICATIONS:

Primary Input Voltage 240V Single-Phase
Imax (A) 40.0
Open Circuit Voltage (OCV) 60.0
Insulation Class H
Dinse Connector 35/50
Suitable Materials MIG: Mild Steel, Stainless Steel, Aluminium, Silicon Bronze
MMA: Mild Steel, Stainless Steel, Cast Iron
TIG: Mild Steel, Stainless Steel, Copper, Silicon Bronze
Supply Plug 15A
Ieff (A) 15.1
Protection Class IP23S
Minimum Generator (kVA) 12.0
Standard AS 60974.1
Weight (kg) 15.10
Warranty 5 Years
Dimensions (LxWxH) 560 x 220 x 400mm

MIG SPECIFICATIONS:

MIG Current Range 30-220A
MIG Wire Sizes 0.6-1.2mm
MIG Welding Thickness Range 1-10mm
MIG Duty Cycle @ 40°C 15% @ 220A
60% @ 110A
100% @ 85A
MIG Wire Spool Sizes 1kg (D100)
5kg (D200)
Drive Roller Size 30/22

TIG SPECIFICATIONS:

TIG Ignition Type DC Lift Arc
TIG Duty Cycle @ 40°C 15% @ 220A
60% @ 110A
100% @ 85A
TIG Current Range 5-220A
TIG Welding Thickness Range 1-8mm

MMA SPECIFICATIONS:

MMA Current Range 20-180A
MMA Electrode Range 2.5-4.0mm
MMA Duty Cycle @ 40°C 15% @ 180A
60% @ 90A
100% @ 70A
MMA Welding Thickness Range 2-12mm






Part Number/SKU: PK11092

* Product Images are for illustration purposes only, unless otherwise specified colour may be different..
