Goldoni Cluster 70RS Equal Wheel

The new evolution for equal-wheeltractors.
Tapered bodywork, a tight turning radius, four equal driving wheels or the “variant” version, with smaller front wheels for an even tighter turning radius, and the powerful 66 hp direct injection engines are all features that make Cluster the ideal machine for working between the crop rows of vineyards and orchards with low plants and not much room for maneuvering.
The compact bearing structure keeps the center of gravity low and near to the middle of the machine, achieving an optimum weight distribution so that work can be carried out in full safety when evenvery heavy implements are used.
Powerful and reliablewith the new engines.
Cluster tractors feature the new series 66hp 3-cylinder turbo engineswith direct injection. These engines guarantee tip-top performances and a low noise level. They also cut down on consumptions. Designedto provide brilliant results thanks to their optimized power/torqueratio, they can also deliver maximum torque at extremely low enginerates.
Toughly built, complete transmissions.
The transmissions used in the Cluster series of tractors withfour equal-size wheels have been designed to guarantee theright ratio for all jobs while maintaining the simplicity thatmakes them indestructible throughout the years. The twotransmissions available feature precise engagements with limitedlever travel and include a 12+4 synchronized version forCluster SN which provides a 1,4 kph to 35,6 kph forwardspeed range and a 2,4 kph to 25 kph reverse speed range, plusa 16+16 synchronized version with reverse shuttle for theCluster RS and RS REV tractors. The speeds provided by thislatter range from 0,8 kph to 38,7 kph in the forward directionand 0,6 kph to 27,7 kph in reverse.


Tight turning radius.
The steering system of the Cluster RS series is hydraulic,of the power steering type with Load Sensing valve. The 50degree steering angle makes these specialized tractors highlymaneuverable for work between the rows of orchards, vineyards and with the other crops for which they are used.
The truly salient feature.
Goldoni’s Cluster series is right at the very top of its categorywhen it comes to compact size and important weights. The narrow1372 mm wheelbase and 1770 Kg weight make Cluster acompact machine but with the right weight for guaranteeingboth stability and strength. It’s the ideal machine for workingbetween the narrowest crop rows while providing the utmostin comfort for the operator. Goldoni’s Cluster series tractorswith four equal-size wheels provides an excellent wheel gripin every situation, on heavy soil, sloping or rugged ground, also thanks to the front axle, which can swing as far as 15 degrees:the tractor remains firmly on the ground in even the most criticalconditions, providing unexpected driving power for such asmall machine. When he works with one of Goldoni’s Clustertractors, the operator always perceives a high degree of safetyin even extremely difficult work conditions.
Goldoni’s reversible driving system.
Thanks to Goldoni’s reversible driving system, you can workwith extreme precision between even the narrowest rows ofspecialised crops where it would be difficult to work with anyother type of machine. The driver’s seat can be turned through180° in just a few seconds and with a few simple operations.This rotational movement is aided by the transmission’s synchronisedmechanical reverse shuttle, which is effective on allratios.
Hydraulic circuit:a high flow rate for all implements.
The hydraulic circuit, with its 40 l/min flow rate and 2 double-actingsupplementary control valves with quick push-pull couplings,is able to satisfy the requirements of the most modernimplements used for specialized farming purposes.
Rear power lift: strong and powerful.
The rear power lift with horizontal hydraulic links, also availablewith position and draft control, has a 1800 Kg lifting capacity
PTO: power whenever needed.
As part of the standard outfit, Cluster tractors have a 540/750rpm independent PTO that’s synchronized with the gearboxand features a 1” 3/8 profile allowing all the most importantimplements available on the market to be used.
Designed for the people who drive them.
The Cluster series of tractors with equal-size wheels features adriving seat that can be adjusted as to height and distance fromcontrols and is installed an elastic suspensions. This makes work very comfortable for the operator, who must spend many hoursof the day on the job. When it comes to safety, the Cluster series offers a folding safetyframe, all the active and passive protections required by EECstandards, plus soundproofed exhaust pipe and bonnet. Moreover,the Cluster series features the Push & Start safety deviceon the clutch pedal and the lock to hold the power lift’s controllever in the neutral position.
