10×5 Tandem Hydraulic Tipper

We can freight our canopies all around Australia, so please contact us for a freight price to your location. Please see the below prices to freight depot’s at capital cities:
-
Features:
410mm deep checker plate sides
3500kg Gross Vehicle Mass
Optional 800/1000mm removable mesh Galvanised cage with front and rear gates (extra)
2.5mm Full checker plate flooring, sides, guards & gates
Seamless checker plate folded sides with middle seam weld
Full length checker plate side steps to front & rear (both sides)
Full length tie rails on both sides & front and rear gates
Rocker roller suspension with 8mm thick 8 leaf springs (4.5 Tonne Engineer Rated)
50/50mm Solid square axels (6 stud land cruiser pattern)
Parallel NTN brand Japanese wheel bearings
50mm Quick release 3500kg coupling
50/50/3mm Crossrails (top chassis)
Crossrails spaced 330mm apart (top chassis)
100/50/3mm outer chassis frame & middle chassis frame (top chassis)
Bottom chassis constructed from 100/50/4mm
Double folded 45 degree mud guard tips
5 Stage hydraulic ram (5 Tonne rated)
Wireless remote & extended hard wire control
100/50/5mm Drawbar (1.8m Long)
Four wheel electric brakes with brake away unit
Handbrake
5 x Brand new 15 inch White Sunraysia wheels (including spare)
5 x Brand new 215/70R15 tubeless tyres
Swing-up heavy duty 10 Inch jockey wheel
LED lights with checker plate guards
LED side clearance lights
Compliance plate
Three year structural warranty
-
Freight Prices:
 – Melbourne – Free Pickup  – Sydney $450  – Canberra $500  – Adelaide $500  – Brisbane $950  – Tasmania $808
-
Prices may be subject to change, please contact us for confirmation on our latest products and prices.
