B&W 702 S3 Floorstanders in Rosenut

Presenting the all new 702 S3

Proudly brought to you by Bowers & Wilkins

702 S3's Carbon Dome tweeter is housed in an all-new Solid Body Tweeter assembly, while with its new downward-firing port configuration and trio of Aerofoil Profile bass cones, it delivers bass that’s both profoundly deep and endlessly articulate.

Goosebumps guaranteed

B&W flagship, the 702 S3, is a state-of-the-art floor-standing speaker that defines new standards for performance in its class. If you want the best, this is it.

A house for high frequencies

The 700 Series features the latest generation of our iconic Solid Body Tweeter-on-Top housing. Its new, more elongated form incorporates a longer tube-loading system to produce an even more free and open sound with high frequencies. The carefully decoupled housing is milled from a single solid block of aluminium to better resist resonance.

Sharper detail

Carbon Dome tweeters are purpose-built for the 700 Series. Delivering a dramatic improvement on the aluminium double dome tweeter, they raise the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail.

Truly amazing sound

Thanks to its composite construction, the Continuum™ cone avoids the abrupt transitions in behaviour that can impair the performance of a conventional drive unit. The result is a more open, neutral performance that delivers voices and instruments with precision and transparency.

Clean and clear

Every three-way loudspeaker in the new 700 Series has a dedicated midrange cone using four key Bowers & Wilkins technologies: the Continuum cone, FST™, Biomimetic Suspension and midrange decoupling, the latter ensuring minimal interference from the operation of the loudspeaker’s bass drivers.

A triumph of science

Developed using advanced computer modelling techniques, the Aerofoil™ Profile bass cone has variable thickness, providing stiffness and rigidity where it’s needed most. The result: deep and dynamic bass.

Upgrades and improvements on the previous model - 702 “S2”
Narrower cabinet
Curved baffle with protruding drivers
Anodised solid body tweeter-on-top with improved decoupling
Downward-firing port
Improved plinth with metal legs (30mm long) and M10 stainless steel spikes
Improved terminal tray
Upgraded motors, chassis and crossover
Biomimetic Suspension
Product Features
Decoupled Carbon Dome tweeter
Solid Body Tweeter-on-Top
Continuum™ cone FST™ midrange
Decoupled midrange
Aerofoil™ Profile bass cones
Flowport™
Technical Specifications

Description
3-way vented-box system

Drive units
1x ø25mm (1in) Decoupled Carbon Dome high-frequency
1x ø150mm (6in) Continuum cone FST midrange
3x ø165mm (6.5in) Aerofoil Profile bass

Frequency range
28Hz to 33kHz

Frequency response (+/-3dB from reference axis)
46Hz – 28kHz

Sensitivity (on axis at 2.83 Vrms at 1m)
90dB

Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)
Nominal impedance
8Ω (minimum 3.1Ω

Recommended amplifier power
30W – 300W into 8Ω on unclipped programme

Max. recommended cable impedance
0.1Ω

Cabinet Finishes
Gloss black
Satin white
Mocha
Rosenut

Grille
Black
Grey (Satin White only)

Dimensions & Weight

Height
1010mm (39.8in) cabinet only
1138mm (44.8in) including tweeter and plinth

Width
192mm (7.6in) cabinet only
290mm (11.4in) including plinth

Depth
354mm (13.9in) cabinet only
391mm (15.4in) including grille and terminals
410mm (16.1in) including plinth



*This information has been obtained from Manufacturers website. We advise that Features, Specifications & Price are subject change without notice.

E&OE
