Ortofon Cadenza Blue MC Phono Cartridge

Ortofon Cadenza Blue technical data

The Cadenza Blue model is using a Nude FG 70 stylus with a very thin ruby cantilever. The improved winding process on the armature ensures better channel balance.

The soundstage of Cadenza Blue is wide open and grandiose straight out of the box. Micro dynamic and ambience will be evident when listening to complex compositions. It reaches a very high degree of definition in the perspective, which is very present. It is true to the music with a tremendous clarity.



Technical Data
Output voltage at 1 kHz 5 cm/sec 500 μV
Channel balance
Channel separation at 1 kHz > 23 dB
Channel separation at 15 kHz > 15 dB
Frequency range at -3 dB 20 Hz - 50 kHz
Frequency response 20 Hz - 20 kHz -2
Tracking ability at 315 Hz at recommended tracking force *) 80 μm
Compliance, dynamic, lateral 12 μm/mN
Stylus type Nude FG 70, Ruby cantilever
Stylus tip radius r/R 6/70
Tracking force range 2,2-2,7 g (22-27 mN)
Tracking force recommended 2,5 g (25 mN)
Tracking angle 20º
Internal impedance, DC resistance 5 Ohm
Recommended load impedance 50-200 Ohm
Cartridge body material Stainless steel Aluminium
Cartridge colour Blue/Black
Cartridge weight 10,7 g



*reprint form manufacturers website
