FOR HIRE DEVELON DX62Z-7 6.2T TRACKED EXCAVATOR
Contact us for further information on availability and rates
1800 SEM HIRE
[email protected]
_______________________
The DEVELON DX62Z-7 6.2T Tracked Excavator delivers outstanding power, precision, and versatility in a compact zero tail swing design. Built for demanding civil construction, commercial projects, utilities, demolition, and large-scale earthmoving, the DX62Z-7 provides exceptional performance while maintaining the manoeuvrability needed to work efficiently in confined spaces.

Powered by a reliable, fuel-efficient diesel engine and featuring DEVELON's advanced hydraulic system, the DX62Z-7 offers smooth, responsive controls, impressive breakout force, and excellent lifting capability. The spacious operator's cabin is designed for all-day comfort, with ergonomic controls, outstanding visibility, climate control, and a premium operating environment to maximise productivity on every job.

With an operating weight of approximately 6.4 tonnes and a maximum digging depth of over 4.1 metres, the DX62Z-7 is well suited to a wide variety of excavation and construction applications. Its zero tail swing design allows operators to work safely and confidently alongside buildings, fences, and other obstacles without compromising performance.

Perfect for:

Civil construction and infrastructure projects
Bulk excavation and detailed earthworks
Trenching and underground service installation
Commercial and residential construction
Demolition and site preparation
General earthmoving and landscaping

Available for short-term or long-term hire with competitive rates. Contact our team today to discuss your project requirements and secure the DEVELON DX62Z-7 for your next project.
SPECIFICATIONS DIMENSION & WORKING RANGE

MACHINE DIMENSIONS

WORKING RANGE

ENGINE
Model Develon D24
Number of cylinders 4
Rated power at 2200 rpm SAE J1995 44.3 kW (65 hp)
Max. torque at 1600 rpm 260 Nm
Idle (low - high) 1000 - 2300 rpm
Displacement 2392 cm3
Bore stroke 90 mm 94 mm
Starter 12 V / 2.5 kW
Batteries - Alternator 1 12 V, 100 Ah 12 V, 90 A
Air filter Double element air cleaner

DRIVE SYSTEM
Travel speed (low - high) 2.8 - 4.7 km/h
Maximum traction 4.58 t
Maximum gradeability 35 / 70%
SWING MECHANISM
Maximum swing speed 9.8 rpm
Maximum swing torque 1380 kgfm
HYDRAULICS
Main pump 144.9 l/min

DX62R-7 DX63-7
Implement 280 kgf/cm2
Travel 280 kgf/cm2
Swing 220 kgf/cm2

Unit DX50Z-7M DX55R-7M
Boom type mm 2900 2900
Arm type mm 1900 1900
Bucket capacity m3 0.175 0.175
Undercarriage (track + grouser) - Rubber Rubber
L1 Overall length mm 5631 5571
H1 Overall height

Boom mm 2385
Cab mm 2575
W1 Overall width mm 1980
R1 Rear swing radius mm 1180 1350
H2 Ground clearance mm 208
L2 Rear end distance mm 1180 1350
W2 House width mm 1750
W3 Cab width mm 1150
H3 Height over cover mm 1588
H4 Counterweight clearance mm 628
A1/
A2
Boom swing angle (left/right) 60/53
H5 Track height mm 562
L3 Track length mm 2486
L4 Tumbler distance mm 1990
W4 Track gauge mm 1580
W5 Undercarriage width mm 1980
W6 Shoe width mm 400
etc. Grouser height mm 20
H6 Dozer digging depth mm 460
H8 Dozer lift clearance mm 488
H9 Dozer blade height mm 410
L8 Distance to dozer end mm 1840

Unit DX62R-7 DX63-7
Boom length mm 2900 2900
Arm length mm 1900 1600 1900 1600
Bucket capacity m3 0.175 0.175
A Max. digging reach mm 6610 6310 6440 6140
B Max. digging reach (ground) mm 6485 6175 6315 6005
C Max. digging depth mm 4095 3795 4095 3795
D Max. dumping height mm 4270 4040 4270 4040
E Min. swing radius mm 2850 2685 2680 2515
F Max. digging height mm 6025 5790 6025 5790
G Max. bucket pin height mm 5155 4925 5155 4925
H Max. vertical wall depth mm 2580 2380 2580 2380
I Max. radius vertical mm 5155 4935 4985 4765
