LCT1631A MPEG2 HD DIGITAL MODULATOR W/HDMI COMPONENT COMPOSITE INPUTS - ZyCast

The LCT-1631A is a cost-effective, single input MPEG-2 HDEncoder/Modulator that converts Digital Video Broadcasting (DVB) high definition video and audio signalsto COFDM. The unit's front-mounted LCD allows for easy configuration and adjustments.This compact and economical modulator is perfect for multi-video distribution solutions in the commercial and institutional market (hotels, motels, sports bars, restaurants, hospitals, casinos, business and university campuses, digital signage, etc.) as well as home entertainment systems. Features HDMI, Component, Composite Inputs, RF Output Gain Control (20dB Manual Attenuation) RJ-45 port for Web Management Video resolution: Up to 1080i/1080p Perfect, clean and clear HD picture on high motion video, sports, text crawls/rolls, etc. Front Panel LCD Cool & silent operation Specifications Video / Audio Input HDMI 1.4 Connector Single Audio Embedded PCM HDCP Compliance (Test Mode) 1.4 Component / Composite Connector RCA x1 Set for Each Audio Analog 3.5mm (Phone Jack) Video/ Audio Encoding Profile Video Video Codecs MPEG-2 VBR   Bitrate (Adjustable) DVB-T: HD: 12.0 to 24.0Mbps (Suggested Max. Bitrate 17Mbps for 16-QAM) SD: 4.0 to 9.0Mbps   Resolution Output Same as Input, Accepting Resolution as Follows: 1080p30 / 1080p25 1080i60 / 1080i50 720p60 / 720p50 576p / 480p 576i / 480i Audio Audio Codecs MPEG1 Layer II / MPEG4 AAC /AC-3 Encode Output Standard DVB-T Connector 1x “F” Female Output Level 95 dBµV Typical (With 20dB Range Manually Adjustable) Flatness Across Full Band ± 2 dB Typical MER 38 dB Typical @ 480.5 MHz under DVB-T Mode Output Impedance 75 ohm RF Output Return Loss 10 dB Typical ModulatorSTD DVB-T (COFDM) RF Mode Normal / Inverted   Frequency Range (AU / NZ) AU: 104.5 MHz to 816.5 MHz (Channel 5 to Channel 69) NZ : 107.5 MHz to 858.0 MHz (Channel S1 to Channel 69) Constellation (Output Bitrate, Max.) AU : 64-QAM (27.70Mbps) NZ : 64-QAM (31.66 Mbps) FEC 7/8 LCN Mode AU / NZ OFDM Mode 2k, 8k Guard Interval 1/32 General Local Monitoring LCD Web GUI Supported Firefox, Chrome Password Protected GUI: User Settable Power Supply 12VDC 1.5A Consumption 5W Operation Temperature 0°C to +55°C Storage Temperature -20°C to +70°C Dimension Housing: 236(L) x 145(W) x 34(H) mm Weight TBD Language English Package Contents LCT-1631A Encoder / Modulator 12V DC 1.5A Power Adapter 3.5mm to 2 RCA Audio Lead One installation / configuration manual Brand: ZyCast Visit our website to view thousands more products like this and order online at:
